Hybrid Solar Wind Controller, 3000 W 0~1500 W Wind 0~1500 W MPPT Solar Hybrid Solar Wind Controller Pioneer Version Charge Lithium Battery and Lead Acid Gel

Specification:Maximum input voltage: wind turbine≤80Vsolar panel≤95VNo-load current (DC): ≤0.05AController power supply mode: battery or solarControl mode: wind turbine MPPT boost charge, PWM discharge charge, PWM over current limitation functionOutput operating modes (modes): mode 1: light control on. Light control off (3 adjustable modes)Display content: LCD display, voltage, battery power percentage, current, load work mode, etc.Protection type: solar reverse charge protection, battery open circuit protection, battery reverse connection protection, automatic brake protection from overcurrent and overvoltage, overload protection, etc.Cooling mode: aluminium profiles Heat dissipation and self-coolingWorking temperature / relative humidity: -25 °C ~ 80 °C / 0 ~ 90%, non-condensingNet weight: 2.35kgController dimensions: 167mm * 145.5 mm * 61.8 mmpacked: 1x solar wind hybrid charge controllerNote:1. Correct connection sequence:1) pls connect the wires between battery and contr

• Specially designed for solar wind hybrid street lighting and security monitoring system. Intelligent design and simple operation suitable for domestic residential power supply system?
• Workable for sealed battery (GEL, lead-acid) and lithium. Many parameters can be set such as: system voltage, battery type, charging Breeze?
• The working mode of the discharge part can be set in light control mode and time control model? Large LCD screen and four-button operation mode easier and more convenient for the user;
• counter-foot lighting, solar charger, automatic over-voltage braking, reverse connection of storage battery and open protection, etc.
• For independent design, Wind adopts MPPT booster to generate low wind speed; Solar PWM charging reduces self-consumption and the system is more stable.
